The SS2H10-E3/52T is a Schottky Barrier Rectifier manufactured by Vishay Semiconductors. It is designed to provide efficient rectification with a low forward voltage drop. This device is well-suited for applications where power efficiency and minimal heat dissipation are crucial.

Applications

• Switching mode power supplies
• High-frequency DC-DC converters
• Reverse polarity protection circuits
• Freewheeling diodes in inductive loads
• Portable electronic devices

Features

• Low forward voltage drop: Minimizes power loss and improves efficiency.
• High surge current capability: Provides protection against transient voltage spikes.
• High-temperature soldering guaranteed: Ensures reliable soldering during assembly.
• RoHS compliant: Meets environmental standards for lead-free manufacturing.
• Low power loss, high efficiency

Benefits

• Increased energy efficiency: Reduces power consumption and heat generation.
• Improved system reliability: Protects against voltage transients and reverse polarity.
• Simplified assembly process: Compatible with automated manufacturing techniques.
• Environmentally friendly: Complies with RoHS regulations, reducing environmental impact.
• Longer lifespan due to reduced heat stress

Technical Specifications

The SS2H10-E3/52T has a maximum repetitive peak reverse voltage (VRRM) of 100V and a maximum average forward rectified current (IF(AV)) of 2A. The forward voltage (VF) is typically 0.7V at 2A. The operating junction temperature range is -55°C to +150°C. It is available in a DO-220AA (SMP) package. The maximum peak surge current is 75A. The low reverse leakage current contributes to energy savings. It is optimized for high-frequency operation, minimizing switching losses. The device is designed with a robust construction to withstand harsh environmental conditions.
