SMBJ5.0CA-E3/52 Real Image SMBJ5.0CA-E3/52 real image5603
Same model may have multiple batches, images only for reference.
SMBJ5.0CA-E3/52 Real Image SMBJ5.0CA-E3/52 real image5603
SMBJ5.0CA-E3/52 Real Image SMBJ5.0CA-E3/52 real image5603
Same model may have multiple batches, images only for reference.

SMBJ5.0CA-E3/52

Part No SMBJ5.0CA-E3/52
Manufacturer Vishay
Catalog TVS - Diodes
Description TVS Diode Single Bi-Dir 5V 600W 2-Pin SMB T/R / TVS DIODE 5VWM 9.2VC SMB
Datasheet
SMBJ5.0CA-E3/52 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 5V
Minimum Breakdown Voltage 6.4V
Max Clamping Voltage 9.2V
Peak Pulse Current(Ippm) 65.2A
Power Dissipation - Pd 600W
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package DO-214AA (SMBJ)
Win Source Part Number 029238-SMBJ5.0CA-E3/52
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Automotive, Computers & Computer Peripherals, Communications & Networking, Consumer Electronics, Lighting, Sensing & Instrumentation, Industrial
Quantity per package 750
Family Name SMBJ5.0CA
Introduction Date February 01, 1999
ECCN EAR99
Country of Origin China
Halogen Free Not Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SMBJ5.0CA-E3/52 CAD Model

Description

The Vishay SMBJ5.0CA-E3/52 is a Zener diode designed for general-purpose applications.

  • Manufacturer: Vishay
  • Application: general-purpose
  • Channel: bidirectional
  • Mounting: SMD (SMT)
  • Family: SMBJ5.0CA
  • Category: circuit protection
  • Status: active
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Case/Package: DO-214AA (SMBJ)
  • STAND-OFF voltage (Vwm): 5V
  • Minimum Breakdown Voltage: 6.4V
  • Maximum Clamping Voltage: 9.2V
  • Peak Pulse Current (Ippm): 65.2A
  • Power Dissipation (Pd): 600W
  • Applications: automotive, computers and computer peripherals, communications and networking, consumer electronics, lighting, sensing and instrumentation, and industrial applications
  • Estimated EOL Date: 2027
