SMBJ3V3-E3/52 Real Image SMBJ3V3-E3/52 label picture SMBJ3V3-E3/52 real image SMBJ3V3-E3/52 real image5598
Same model may have multiple batches, images only for reference.
SMBJ3V3-E3/52 Real Image SMBJ3V3-E3/52 label picture SMBJ3V3-E3/52 real image SMBJ3V3-E3/52 real image5598
SMBJ3V3-E3/52 Real Image SMBJ3V3-E3/52 label picture SMBJ3V3-E3/52 real image SMBJ3V3-E3/52 real image5598
Same model may have multiple batches, images only for reference.

SMBJ3V3-E3/52

Part No SMBJ3V3-E3/52
Manufacturer Vishay
Catalog TVS - Diodes
Description TVS Diode Single Uni-Dir 3.3V 600W 2-Pin SMB T/R / TVS DIODE 3.3VWM 10.3VC SMB
Datasheet
SMBJ3V3-E3/52 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 3.3V
Minimum Breakdown Voltage 4.1V
Max Clamping Voltage 10.3V
Peak Pulse Current(Ippm) 200A (8/20μs)
Power Dissipation - Pd 600W
Applications General Purpose
Capacitance @ Frequency 5200pF @ 1MHz
Temperature Range - Operating -65°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package DO-214AA (SMBJ)
Win Source Part Number 029216-SMBJ3V3-E3/52
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SMBJ3V3
Introduction Date September 25, 2006
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SMBJ3V3-E3/52 CAD Model

Description

The Vishay SMBJ3V3-E3/52 is a Zener type electronic component that is suitable for general purposes.

  • Supply and Demand: balanced
  • Operating Temperature: -65°C to 175°C (TJ)
  • STAND-OFF Voltage (Vwm): 3.3V
  • Minimum Breakdown Voltage: 4.1V
  • Max Clamping Voltage: 10.3V
  • Peak Pulse Current (Ippm): 200A (8/20μs)
  • Power Dissipation (Pd): 600W
