MMU01020C1509FB300 Vishay MMU01020C1509FB300 Real Image MMU01020C1509FB300 label picture 2 MMU01020C1509FB300 real image
Same model may have multiple batches, images only for reference.
MMU01020C1509FB300 Vishay MMU01020C1509FB300 Real Image MMU01020C1509FB300 label picture 2 MMU01020C1509FB300 real image
MMU01020C1509FB300 Vishay MMU01020C1509FB300 Real Image MMU01020C1509FB300 label picture 2 MMU01020C1509FB300 real image
Same model may have multiple batches, images only for reference.

MMU01020C1509FB300

Part No MMU01020C1509FB300
Manufacturer Vishay
Catalog Chip Resistor - Surface Mount
Description MMU 0102-50 1% BL 15R / 15 Ohms ±1% 0.3W Chip Resistor MELF, 0102 Anti-Sulfur, Automotive AEC-Q200, Pulse Withstanding Thin Film
Datasheet
MMU01020C1509FB300 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Resistors - Chip Resistor - Surface Mount
Mfr Vishay
Series MMU - Professional
Package Tape & Reel
Product Status Active
Resistance 15 Ohms
Tolerance ±1%
Power (Watts) 0.3W
Composition Thin Film
Features Anti-Sulfur, Automotive AEC-Q200, Pulse Withstanding
Temperature Coefficient ±50ppm/°C
Temperature Range - Operating -55°C ~ 155°C
Package / Case MELF, 0102
Supplier Device Package 0102
Ratings AEC-Q200
Size / Dimension 0.055" Dia x 0.142" L (1.40mm x 3.60mm)
Number of Terminations 2
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.21.0040
Win Source Part Number 747604-MMU01020C1509FB300
Ultra Librarian 3D Model Ultra Librarian MMU01020C1509FB300 CAD Model

Description

The 747604-MMU01020C1509FB300 is a chip resistor with a surface mount package.

  • Series: MMU
  • Size: 0.055" diameter and 0.142" length
  • Tolerance: ±1%
  • Temperature Coefficient: ±50ppm/°C
  • AEC-Q200: Yes
  • Power Rating: 0.3W
  • Resistance: 15 Ohms
  • Composition: Thin film
  • Terminations: Two
  • Case: MELF, 0102
  • Operating Temperature Range: -55°C to 155°C
  • Manufacturer: Vishay
  • Standard Package: 3,000 pcs
