LL4148-GS08 Vishay LL4148-GS08 Real Image LL4148-GS08 label picture 2 LL4148-GS08 label picture 3 LL4148-GS08 label picture 4 LL4148-GS08 label picture 5 LL4148-GS08 label picture 6 LL4148-GS08 real image LL4148-GS08 real image 2 LL4148-GS08 label picture 7 LL4148-GS08 real image 3
Same model may have multiple batches, images only for reference.
LL4148-GS08 Vishay LL4148-GS08 Real Image LL4148-GS08 label picture 2 LL4148-GS08 label picture 3 LL4148-GS08 label picture 4 LL4148-GS08 label picture 5 LL4148-GS08 label picture 6 LL4148-GS08 real image LL4148-GS08 real image 2 LL4148-GS08 label picture 7 LL4148-GS08 real image 3
LL4148-GS08 Vishay LL4148-GS08 Real Image LL4148-GS08 label picture 2 LL4148-GS08 label picture 3 LL4148-GS08 label picture 4 LL4148-GS08 label picture 5 LL4148-GS08 label picture 6 LL4148-GS08 real image LL4148-GS08 real image 2 LL4148-GS08 label picture 7 LL4148-GS08 real image 3
Same model may have multiple batches, images only for reference.

LL4148-GS08

Part No LL4148-GS08
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 75V 300MA SOD80
Datasheet
LL4148-GS08 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 75V
Current - Average Rectified (Io) 300mA (DC)
Voltage - Forward (Vf) (Max) @ If 1V @ 50mA
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 4ns
Current - Reverse Leakage @ Vr 5μA @ 75V
Capacitance @ Vr, F 4pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package SOD-80 MiniMELF
Operating Temperature - Junction -65°C to 175°C
Win Source Part Number 018625-LL4148-GS08
Family Name LL4148
Introduction Date April 02, 1998
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Signal Processing, Power Management, Consumer Electronics, Portable Devices, Automotive
Ultra Librarian 3D Model Ultra Librarian LL4148-GS08 CAD Model

Description

The Vishay LL4148 is a standard diode that is suitable for use in signal processing, power management, consumer electronics, portable devices, and automotive applications.

  • Voltage Rating: 75V
  • Current Rating: 300mA
  • Forward Voltage Drop: 1V @ 50mA
  • Reverse Recovery Time: 4ns
  • Package: SOD-80 MiniMELF
  • Packaging: Reel
  • Capacitance: 4pF @ 0V, 1MHz
  • Operating Temperature Range: -65°C to 175°C
  • Compliance: Halogen-free regulations
  • Popularity: High
  • Supply and Demand Status: Sufficient
