DG413HSDY-T1-E3 Vishay DG413HSDY-T1-E3 Real Image DG413HSDY-T1-E3 label picture 2 DG413HSDY-T1-E3 real image
Same model may have multiple batches, images only for reference.
DG413HSDY-T1-E3 Vishay DG413HSDY-T1-E3 Real Image DG413HSDY-T1-E3 label picture 2 DG413HSDY-T1-E3 real image
DG413HSDY-T1-E3 Vishay DG413HSDY-T1-E3 Real Image DG413HSDY-T1-E3 label picture 2 DG413HSDY-T1-E3 real image
Same model may have multiple batches, images only for reference.

DG413HSDY-T1-E3

Part No DG413HSDY-T1-E3
Manufacturer Vishay
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description Analog Switch Quad SPST 16-Pin SOIC N T/R / IC SWITCH QUAD SPST 16-SOIC
Datasheet
DG413HSDY-T1-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Vishay
Packaging Reel - TR
Status Active
Switch Circuit SPST - NO/NC
Number of Circuits 4
Max On Resistance 35 Ohm
Single Supply Voltage (V+) 12V
Dual Supply Voltage(V±) ±5 V to 20 V
Max Switch Time (Ton,Toff) 105ns, 80ns
Charge Injection 22pC
Channel Capacitance(CS off, CD off) 12pF, 12pF
Max Leakage Current (IS off) 250pA
Crosstalk -88dB @ 1MHz
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 16-SOIC
Win Source Part Number 014272-DG413HSDY-T1-E3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name DG413HS
Introduction Date February 03, 2003
ECCN EAR99
Country of Origin Philippines, Taiwan
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian DG413HSDY-T1-E3 CAD Model

Description

DG413HSDY-T1-E3 - High-Speed Analog Switch

Discover top-tier performance with the DG413HSDY-T1-E3, an analog switch that provides unmatched speed and precision. Suited for high-frequency uses, it guarantees crisp and clear signal transmission.

  • Applications:
    • Broadcasting Equipment
    • Radar Systems
    • Satellite Communication
    • High-Speed Data Links
  • Features and Benefits:
    • Ultra-Fast Switching: Maximizes efficiency in high-speed environments.
    • Precision Control: Ensures signals are transmitted accurately without degradation.
    • Enhanced Noise Immunity: Reduces disturbances in signal pathways.
    • Rugged Build: Withstands rigorous usage without performance loss.

Additional Details: The DG413HSDY-T1-E3 is built for speed and precision, making it the ideal choice for applications needing rapid and reliable signal switching.
