DF06S-E3/77 Vishay
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 600V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 1A
Current - Reverse Leakage @ Vr 5μA @ 600V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package DFS
Win Source Part Number 014125-DF06S-E3/77
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name DF06S
Introduction Date June 13, 2006
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian DF06S-E3/77 CAD Model

Description

Product Overview

The DF06S-E3/77 is a versatile bridge rectifier diode designed to handle significant power demands. This component boasts high efficiency and reliability, making it perfect for a variety of electronics and industrial applications.

Features and Benefits

  • Strong overload and peak forward surge current capability
  • Low reverse leakage current
  • Excellent temperature stability
  • Industry-standard case for easy integration

Applications

  • Inverters
  • Welding equipment
  • AC to DC convertors
  • Electrical heaters

The DF06S-E3/77 provides outstanding performance, ensuring the integrity and efficiency of power conversion circuits across various uses.
