12CWQ10FNTRPBF Real Image 12CWQ10FNTRPBF label picture
Same model may have multiple batches, images only for reference.
12CWQ10FNTRPBF Real Image 12CWQ10FNTRPBF label picture
12CWQ10FNTRPBF Real Image 12CWQ10FNTRPBF label picture
Same model may have multiple batches, images only for reference.

12CWQ10FNTRPBF

Part No 12CWQ10FNTRPBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 100V DPAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) (per Diode) 6A
Voltage - Forward (Vf) (Max) @ If 800mV @ 6A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1mA @ 100V
Operating Temperature - Junction -55°C to 150°C
Mounting SMD (SMT)
Case / Package D-PAK (TO-252AA)
Win Source Part Number 093058-12CWQ10FNTRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 12CWQ10FNTRPBF CAD Model

Description

12CWQ10FNTRPBF Schottky Diode

This diode is engineered for critical power management applications, ensuring efficiency with its low forward voltage characteristics and superior thermal performance.

  • Applications: Power adapters, Industrial power systems, Switching power supplies
  • Features and Benefits:
    • Extended operating voltage range for flexibility
    • Lead-free for reduced environmental impact
    • Improved surge capacity assures longevity
  • Additional Details: Noteworthy for its robustness in complex power circuits.
