The GDH04S04 is a DIP (Dual In-Line Package) switch manufactured by Tyco Electronics. This switch is designed for use in a variety of electronic applications where manual configuration or programming is required.

Applications:

• Circuit board configuration
• Address setting
• Function selection
• Test equipment
• Industrial control panels

Features:

• 4-position DIP switch
• Through-hole mounting
• Raised actuator
• Gold-plated contacts
• Sealed construction

Benefits:

• Easy manual configuration
• Reliable electrical connection
• Prevents contamination
• Long life and durability
• Simple integration into circuit boards

Additional Details:

The GDH04S04 DIP switch features four individual switches in a single package. The through-hole mounting style allows for easy insertion and soldering onto printed circuit boards. The raised actuator design makes it easy to operate the switches manually, even in confined spaces. The gold-plated contacts ensure a reliable electrical connection and prevent corrosion. The sealed construction protects the switch from dust, moisture, and other contaminants, ensuring long-term performance and reliability.

This DIP switch is commonly used in applications where settings need to be changed infrequently, such as configuring the address of a device on a network or selecting a particular function in an electronic system. Its robust construction and reliable performance make it a suitable choice for a wide range of industrial, commercial, and consumer electronic applications. The switch is designed to meet industry standards for safety and performance, ensuring a dependable and long-lasting solution for manual configuration needs.
