9HT7-32.768KBZF-T TXC CORPORATION – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

9HT7-32.768KBZF-T

Part No 9HT7-32.768KBZF-T
Manufacturer TXC CORPORATION
Catalog Crystals
Description CRYSTAL 32.7680KHZ 12.5PF SMD
Datasheet
9HT7-32.768KBZF-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type kHz Crystal (Tuning Fork)
Frequency 32.768 kHz
Frequency Tolerance ±50ppm
Load Capacitance 12.5pF
ESR (Equivalent Series Resistance) 65 kOhms
Operating Mode Fundamental
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Case / Package 4-SMD, Flat Leads
Size / Dimension 0.264" L x 0.055" W (6.70mm x 1.40mm)
Height - Seated (Max) 0.055\
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1528568-9HT7-32.768KBZF-T
Ultra Librarian 3D Model Ultra Librarian 9HT7-32.768KBZF-T CAD Model
