HM78D-7556R8MLFTR TT Electronics – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

HM78D-7556R8MLFTR

Part No HM78D-7556R8MLFTR
Manufacturer TT Electronics
Catalog Arrays, Signal Transformers
Description INDUCT ARRAY 2 COIL 6.8UH SMD
Datasheet
HM78D-7556R8MLFTR Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Number of Coils 2
Inductance - Connected In Parallel 6.8 µH
Inductance - Connected In Series 29.38 µH
Tolerance ±20%
Current Rating - Parallel 2.6 A
Current Rating - Series 1.3 A
Current Saturation - Parallel 3.67 A
Current Saturation - Series 1.84 A
DC Resistance (DCR) - Parallel 41.8mOhm
DC Resistance (DCR) - Series 167mOhm
Shielding Shielded
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Case / Package Nonstandard
Size / Dimension 0.303" L x 0.303" W (7.70mm x 7.70mm)
Height 0.189\
Package Cut Tape (CT)
Supply and Demand Status Shortage
Win Source Part Number 1530701-HM78D-7556R8MLFTR
Ultra Librarian 3D Model Ultra Librarian HM78D-7556R8MLFTR CAD Model
