The TEM3-2411 is a 3-Watt isolated DC-DC converter manufactured by TRACO Electronic AG. This module is designed to provide a regulated output voltage from a DC input source, with electrical isolation between the input and output. It is commonly used in applications requiring safety isolation, ground loop elimination, or voltage level conversion.

Applications

• Industrial control systems requiring isolated power.
• Medical equipment needing safety isolation for patient protection.
• Instrumentation and measurement devices to eliminate ground loops.
• Telecommunications equipment for power distribution and isolation.
• Portable electronic devices needing efficient DC-DC conversion.
• Use in transportation electronics.
• Use in renewable energy systems.

Features

• 3W Output Power: Delivers up to 3 watts of output power.
• 2:1 Input Voltage Range: Supports a wide input voltage range, accommodating variations in the input power source.
• 1500 VDC Isolation: Provides 1500 VDC of isolation between the input and output.
• Regulated Output Voltage: Maintains a stable output voltage even with variations in input voltage or load current.
• Short-Circuit Protection: Protects the converter and connected circuitry from damage due to output short circuits.
• Overload Protection: Limits the output current to prevent damage from excessive load conditions.
• High Efficiency: Operates with high efficiency, minimizing heat dissipation and maximizing energy conversion.

Benefits

• Enhanced Safety: Provides electrical isolation to protect against electrical shock and ground loops.
• Stable Power Supply: Regulated output voltage ensures consistent performance of connected devices.
• Reliable Operation: Built-in protection features enhance the reliability and longevity of the converter.
• Versatile Applications: Wide input voltage range and isolation make it suitable for various applications.
• Compact Size: Small form factor allows for easy integration into space-constrained designs.

Additional Details

The TEM3-2411 accepts a nominal input voltage of 24VDC (range: 18-36VDC) and provides a single output voltage of 11 VDC. It features continuous short-circuit protection and an operating temperature range of -40°C to +85°C (with derating). The isolation voltage is tested at 1500 VDC for 1 minute. The efficiency of the converter is typically around 80%. The package is a compact SIP (Single In-Line Package). The device is compliant with safety standards such as EN 60950-1 and UL 60950-1. Refer to the datasheet for the most accurate and up-to-date specifications and safety certifications.
