TLP3545A(TP1,F Toshiba Semiconductor and Storage TLP3545A(TP1,F Real Image
Same model may have multiple batches, images only for reference.
TLP3545A(TP1,F Toshiba Semiconductor and Storage TLP3545A(TP1,F Real Image
TLP3545A(TP1,F Toshiba Semiconductor and Storage TLP3545A(TP1,F Real Image
Same model may have multiple batches, images only for reference.

TLP3545A(TP1,F

Part No TLP3545A(TP1,F
Manufacturer Toshiba Semiconductor and Storage
Catalog Solid State Relays
Description MOSFET Output Optocouplers Photorelay 4A 60V 2500Vrms 640pF
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Solid State Relays
Mfr Toshiba Semiconductor and Storage
Series TLP3545A
Package Tape & Reel
Mounting SMD (SMT)
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Voltage - Input 1.64VDC
Voltage - Load 0 V ~ 60 V
Load Current 4 A
On-State Resistance (Max) 60 mOhms
Termination Style Gull Wing
Package / Case 6-SMD (0.300", 7.62mm)
Supplier Device Package 6-SMD
Base Product Number TLP3545
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.41.0030
Win Source Part Number 1315948-TLP3545A(TP1,F
Ultra Librarian 3D Model Ultra Librarian TLP3545A(TP1,F CAD Model

Description

This electronic component is a solid state relay from the TLP3545A series.

  • Product Name: TLP3545A
  • Termination Style: Gull wing
  • Package: Tape & reel
  • Mounting Style: SMD (SMT)
  • Input Voltage: 1.64VDC
  • Output Type: AC/DC
  • Circuit: SPST-NO (1 Form A)
  • Maximum On-State Resistance: 60mOhms
  • Load Current: 4A
  • Voltage Load Range: 0V to 60V
  • Manufacturer: Toshiba Semiconductor and Storage
