TLP292-4(GB-TP,E Toshiba Semiconductor and Storage TLP292-4(GB-TP,E real image TLP292-4(GB-TP,E real image11330 TLP292-4(GB-TP,E Real Image1 TLP292-4(GB-TP,E Real Image2 TLP292-4(GB-TP,E Real Image3 TLP292-4(GB-TP,E Real Image4
Same model may have multiple batches, images only for reference.
TLP292-4(GB-TP,E Toshiba Semiconductor and Storage TLP292-4(GB-TP,E real image TLP292-4(GB-TP,E real image11330 TLP292-4(GB-TP,E Real Image1 TLP292-4(GB-TP,E Real Image2 TLP292-4(GB-TP,E Real Image3 TLP292-4(GB-TP,E Real Image4
TLP292-4(GB-TP,E Toshiba Semiconductor and Storage TLP292-4(GB-TP,E real image TLP292-4(GB-TP,E real image11330 TLP292-4(GB-TP,E Real Image1 TLP292-4(GB-TP,E Real Image2 TLP292-4(GB-TP,E Real Image3 TLP292-4(GB-TP,E Real Image4
Same model may have multiple batches, images only for reference.

TLP292-4(GB-TP,E

Part No TLP292-4(GB-TP,E
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV TRANS SO16
Datasheet
TLP292-4(GB-TP,E Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 5mA
Maximum DC Current Transfer Ratio 600% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.25V
Continuous forward current- Max 50mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 16-SO
Win Source Part Number 1108903-TLP292-4(GB-TP,E
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian TLP292-4(GB-TP,E CAD Model

Description

The Toshiba Semiconductor and Storage TLP292-4(GB-TP,E is an active electronic component that is manufactured by Toshiba Semiconductor and Storage.

  • Win Source Part Number: 1108903-TLP292-4(GB-TP,E
  • Channels: 4
  • Maximum Output Voltage: 80V
