TLP291GR Toshiba Semiconductor and Storage
Same model may have multiple batches, images only for reference.

TLP291GR

Part No TLP291GR
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optoisolator Transistor Output 2500Vrms 4 Channel 16-SO
Datasheet
TLP291GR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators
Family Optoisolators - Transistor, Photovoltaic Output
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel(TR)
Number of Channels 4
Voltage - Isolation 2500Vrms
Current Transfer Ratio (Min) 100% @ 5mA
Current Transfer Ratio (Max) 400% @ 5mA
Turn On / Turn Off Time (Typ) 3μs, 3μs
Rise / Fall Time (Typ) 2μs, 3μs
Input Type DC
Output Type Transistor
Voltage - Output (Max) 80V
Current - Output / Channel 50mA
Voltage - Forward (Vf) (Typ) 1.2V
Current - DC Forward (If) (Max) 50mA
Vce Saturation (Max) 400mV
Operating Temperature Range -55°C ~ 110°C
Mounting Style SMD/SMT
Package 16-SOIC (0.179", 4.55mm Width)
Manufacturer Device Package 16-SO
Win Source Part Number 218175-TLP291GR
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian TLP291GR CAD Model

Description

The TLP291GR is an optoisolator with a transistor photovoltaic output.

  • Channels: Four
  • Voltage Isolation: 2500Vrms
  • Current Transfer Ratio: 100% @ 5mA and the maximum is 400% @ 5mA
  • Current Output per Channel: 50mA
  • Rise/Fall Time: 2μs and 3μs respectively
  • Input Type: DC
  • Output Type: Transistor
  • Operating Temperature Range: -55°C to 110°C
  • Mounting: SMD/SMT
  • Package: 16-SOIC (0.179", 4.55mm Width)
