TLP250(F)

Part No TLP250(F)
Manufacturer Toshiba Semiconductor and Storage
Catalog Isolators - Gate Drivers
Description OPTOISO 2.5KV GATE DRIVER 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Tube/Rail
Status Active
Technology Optical Coupling
Number of Channels 1
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 5kV/μs
Propagation Delay tpLH / tpHL (Max) 500ns, 500ns
Current - Output High, Low 500mA, 500mA
Current - Peak Output 1.5A
Forward Voltage 1.6V
Continuous forward current- Max 20mA
Supply Voltage - Operating 15 V to 30 V
Temperature Range - Operating -20°C to 85°C
Mounting Through Hole
Case / Package 8-DIP
Approvals UR
Win Source Part Number 056420-TLP250(F)
Family Name TLP250
Introduction Date May 15, 2001
ECCN EAR99
Country of Origin Japan
Estimated EOL Date 2019
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian TLP250(F) CAD Model

Description

The Toshiba Semiconductor and Storage 056420-TLP250(F) is a high-popularity isolator component with sufficient supply and demand status.

  • Operating Temperature Range: -20°C to 85°C
  • Packaging: tube/rail
  • Common Mode Transient Immunity: 5kV/μs
  • Isolation Voltage: 2500Vrms
  • Family Name: TLP250
  • Case/Package: 8-DIP
  • Alternative Part: HCPL-T250-000E, HCPL-T250#060E, and ACPL-T350-060E
