TLP2161(TP,F) Toshiba Semiconductor and Storage TLP2161(TP,F) Real Image
Same model may have multiple batches, images only for reference.
TLP2161(TP,F) Toshiba Semiconductor and Storage TLP2161(TP,F) Real Image
TLP2161(TP,F) Toshiba Semiconductor and Storage TLP2161(TP,F) Real Image
Same model may have multiple batches, images only for reference.

TLP2161(TP,F)

Part No TLP2161(TP,F)
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Logic Output
Description OPTOISO 2.5KV 2CH PUSH PULL 8SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators - Optoisolators - Logic Output Optoisolators
Mfr Toshiba Semiconductor and Storage
Package Tape & Reel
Product Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Voltage - Isolation 2500Vrms
Common Mode Transient Immunity (Min) 20kV/µs
Input Type DC
Output Type Push-Pull, Totem Pole
Current - Output / Channel 10 mA
Data Rate 15MBd
Propagation Delay tpLH / tpHL (Max) 80ns, 80ns
Rise / Fall Time (Typ) 3ns, 3ns
Voltage - Forward (Vf) (Typ) 1.5V
Current - DC Forward (If) (Max) 10mA
Voltage - Supply 2.7V ~ 5.5V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SO
Base Product Number TLP2161
Standard Package 2,500 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 843780-TLP2161(TP,F)
Ultra Librarian 3D Model Ultra Librarian TLP2161(TP,F) CAD Model

Description

The TLP2161(TP,F) is a logic output optoisolator suitable for various applications.

  • Channels: Dual
  • Output Type: Push-Pull, Totem Pole
  • Data Rate: 15MBd
  • Input: DC
  • Forward Voltage (typical): 1.5V
  • Rise/Fall Time: ~3ns
  • Current Output (per channel): 10mA
  • Voltage Isolation: 2500Vrms
  • Supply Voltage Range: 2.7V to 5.5V
  • Installation: Surface Mount
  • Package: 8-SOIC
  • Operating Temperature Range: -40°C to 125°C
  • Product Status: Active
  • Manufacturer: Toshiba Semiconductor and Storage
