TLP181GR

Name: TLP181GR
Brand: Toshiba Semiconductor and Storage
SKU: 370139
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	TLP181GR
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOCOUPLER TRANS SOIC
Datasheet	TLP181GR Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel - TR
Status	Obsolete(EOL)
Number of Channels	1
Isolation Voltage	3750Vrms
Minimum DC Current Transfer Ratio	100% @ 5mA
Maximum DC Current Transfer Ratio	300% @ 5mA
Switching Turn-On and Turn-Off Time	3μs, 3μs
Rise and Fall Time	2μs, 3μs
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	80V
Channel Output Current	50mA
Forward Voltage	1.15V
Continuous forward current- Max	50mA
Vce Saturation (Max)	400mV
Temperature Range - Operating	-55°C to 110°C
Mounting	SMD (SMT)
Case / Package	6-MFSOP, 4 Lead
Win Source Part Number	094376-TLP181GR
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	TLP181
Introduction Date	February 27, 1998
ECCN	EAR99
Country of Origin	Japan
Estimated EOL Date	Obsolete
Ultra Librarian 3D Model	Ultra Librarian TLP181GR CAD Model

Alternative Products

Description

The TLP181GR is a logic output optocoupler from Toshiba Semiconductor and Storage.

Ideal for: applications requiring high isolation voltage and fast switching speed
Maximum output voltage: 80V
Channel output current: 50mA
DC current transfer ratio: 300% @ 5mA
Vce saturation: 400mV
Performance: high
Reliability: high
