TLP181

Part No TLP181
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optocoupler DC-IN 1-CH Transistor DC-OUT 4-Pin MFSOP T/R / OPTOCOUPLER TRANS SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Obsolete(EOL)
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 5mA
Maximum DC Current Transfer Ratio 300% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.15V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 6-MFSOP, 4 Lead
Win Source Part Number 043176-TLP181
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name TLP181
Introduction Date February 27, 1998
ECCN EAR99
Country of Origin Japan
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian TLP181 CAD Model

Description

TLP181 from Toshiba Semiconductor and Storage is an optoisolator in the transistor, photovoltaic output category used where designers need signal isolation between control and power domains. It is commonly considered for industrial control interfaces, microcontroller I/O isolation, switching feedback paths, power supply monitoring, and general-purpose noise isolation in embedded systems. Engineers typically choose devices in this class to improve system robustness, protect low-voltage logic from high-voltage transients, and support safer interface design in mixed-signal environments. For sourcing and design planning, TLP181 can be relevant in both new builds and maintenance programs, especially where board-level isolation is required in a compact footprint. The current lifecycle status is information not available, so procurement teams should confirm factory status before committing to long-term designs. RoHS compliance information is also not available in the provided data and should be verified directly through the latest Toshiba Semiconductor and Storage datasheet, compliance declaration, or authorized distributor documentation.
