TLP137 Toshiba Semiconductor and Storage TLP137 real image7445 TLP137 Real Image1 TLP137 Real Image2
Same model may have multiple batches, images only for reference.
TLP137 Toshiba Semiconductor and Storage TLP137 real image7445 TLP137 Real Image1 TLP137 Real Image2
TLP137 Toshiba Semiconductor and Storage TLP137 real image7445 TLP137 Real Image1 TLP137 Real Image2
Same model may have multiple batches, images only for reference.

TLP137

Part No TLP137
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV TRANS 6-MFSOP
Datasheet
TLP137 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Tube/Rail
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 1mA
Maximum DC Current Transfer Ratio 1200% @ 1mA
Switching Turn-On and Turn-Off Time 10μs, 8μs
Rise and Fall Time 8μs, 8μs
Input Type DC
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.15V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 6-MFSOP, 5 Lead
Win Source Part Number 056668-TLP137
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TLP137 CAD Model

Description

The Toshiba Semiconductor and Storage TLP137 is an optoisolator component that is designed for use in a variety of applications.

  • Supply and Demand: Balanced
  • Forward Voltage: 1.15V
  • Input Type: DC
  • Number of Channels: 1
  • Vce Saturation (max): 400mV
  • Isolation Voltage: 3750Vrms
  • Packaging: 6-MFSOP, 5 Lead
  • Minimum DC Current Transfer Ratio: 100% @ 1mA
  • Maximum DC Current Transfer Ratio: 1200% @ 1mA
  • Switching Turn-on and Turn-off Time: 10μs, 8μs
  • Rise and Fall Time: 8μs, 8μs
  • Maximum Output Voltage: 80V
  • Channel Output Current: 50mA
  • Continuous Forward Current-Max: 50mA
