Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 2
Gate Type N-Channel MOSFET
Supply Voltage - Operating 8 V to 17 V
Logic Voltage - VIL, VIH 0.8V, 2.5V
Current - Peak Output (Source, Sink) 3A, 3A
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 120V
Rise and Fall Time 8ns, 7ns
Temperature Range - Operating -40°C to 140°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO PowerPad
Win Source Part Number 035753-UCC27201DDAR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name UCC27201
Introduction Date August 01, 2006
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian UCC27201DDAR CAD Model

Description

The UCC27201DDAR from Texas Instruments is a robust high-side and low-side driver designed for a variety of applications that require efficient and reliable switching of power transistors. This driver IC is particularly well-suited for driving N-channel power MOSFETs and IGBTs that operate up to 120V.

Key Features

  • High-Voltage Capability: The UCC27201DDAR can handle high-side voltages up to 120V, making it suitable for a wide range of power applications.
  • High Current Drive: With peak output currents of +/-3A, this driver can effectively switch power transistors at high speeds, reducing switching losses and improving efficiency.
  • Independent Inputs: Separate inputs for high-side and low-side gates provide design flexibility and the ability to implement various control strategies.
  • Bootstrap Operation: The integrated high-voltage diode for bootstrap operation simplifies the design of the high-side drive circuit.
  • Protection Features: The device includes under-voltage lockout (UVLO) for both the high-side and low-side, ensuring reliable operation under low supply conditions.
  • Extended Temperature Range: Capable of operating over an industrial temperature range of -40°C to +140°C, ensuring performance in harsh environments.

Applications

The UCC27201DDAR is versatile and can be used in a range of applications, including:

  • DC to DC converters
  • Motor controllers
  • Power inverters
  • Class-D audio amplifiers
  • Switch Mode Power Supplies (SMPS)

Package and Quality

The UCC27201DDAR is offered in an 8-pin SOIC (DDA) package, providing a compact solution for space-constrained applications. Texas Instruments' commitment to quality ensures that this driver IC is manufactured to the highest standards, delivering reliable and consistent performance for your power management solutions.

For detailed specifications, application circuits, and design resources, visit the Texas Instruments website to access datasheets, technical documentation, and support tools.
