TUSB8041IRGCR

Part No TUSB8041IRGCR
Manufacturer Texas Instruments
Catalog Interface - Controllers
Description Four-Port USB 3.0 Hub
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Protocol USB
Function Hub Controller
Interface USB, GPIO, I2C, SMBus
Standards USB 3.0
Operating Supply Voltage 1.1V, 3.3V
Operating Temperature Range -40°C ~ 85°C
Package 64-VFQFN Exposed Pad
Manufacturer Package 64-VQFN (9x9)
Win Source Part Number 1274999-TUSB8041IRGCR
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name TUSB8041
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TUSB8041IRGCR CAD Model

Description

The TUSB8041IRGCR is a state-of-the-art USB 3.0 hub controller developed by Texas Instruments. This device is designed to expand a single USB 3.0 port into four, allowing multiple devices to be connected to a host system simultaneously. The TUSB8041IRGCR provides a high-performance and cost-effective solution for a variety of applications including desktop and laptop computers, docking stations, monitors, and many other peripherals requiring USB connectivity.

Key Features

  • Compliant with USB 3.0 Specification, and backward compatible with USB 2.0 and USB 1.1.
  • Four downstream ports support SuperSpeed (SS), High-Speed (HS), Full-Speed (FS), and Low-Speed (LS) traffic.
  • Integrated USB 2.0 hub and USB 2.0 to I2C bridge functionality.
  • Supports Battery Charging Specification 1.2 on downstream ports.
  • Configurable port power management.
  • Over-current protection on each downstream port.
  • Optional Serial EEPROM or SMBus interface for custom configurations.
  • Supports individual or ganged power switching and over-current detection.
  • Available in a 64-pin QFN package (RGC).

Applications

The TUSB8041IRGCR is ideal for expanding USB capabilities in a wide range of electronic devices. Its versatile nature makes it suitable for:

  • Desktop and Laptop PCs
  • PC Motherboards
  • Docking Stations
  • Monitors with USB Hub Functionality
  • Peripheral Sharing Devices
  • Port Replicators

Technical Specifications

The controller operates over a wide temperature range and has multiple power-saving modes, making it an excellent choice for energy-efficient designs. It is designed for robust operation, featuring electrostatic discharge (ESD) protection for enhanced durability.

Ordering and Packaging

The TUSB8041IRGCR is available for order in a compact 64-pin QFN (RGC) package, offering a small footprint for space-constrained applications. For detailed ordering and shipping information, consult the Texas Instruments website or contact an authorized distributor.
