Overview of TUSB2036VFR USB Hub Controller

The TUSB2036VFR is a versatile USB hub controller integrated circuit from Texas Instruments designed to expand a single USB port into multiple ports with full compliance to the Universal Serial Bus Specification Rev. 1.1. This device is particularly suitable for applications requiring up to six downstream ports, providing a cost-effective solution for enhancing USB connectivity in a variety of systems.

Key Features

• USB Interface: The TUSB2036VFR supports a 12-Mbps full-speed USB interface, ensuring compatibility with a wide range of USB devices.
• Port Expansion: It provides three or six downstream ports, which can be configured via hardware or software settings, making it a flexible choice for different application needs.
• Integrated PHY: The device includes an onboard transceiver and a serial interface engine, which minimizes the need for external components and simplifies the design process.
• Power Management: Each downstream port has over-current sensing and reporting capabilities, enhancing the safety and reliability of the connected devices.
• Customization: The hub controller supports optional EEPROM or pull-up resistor configurations for custom VID/PID and device attributes, allowing designers to tailor the device to specific product requirements.

Applications

The TUSB2036VFR is ideal for a broad range of applications, including but not limited to desktop and notebook PCs, docking stations, monitors with USB hubs, standalone USB hubs, and peripheral devices requiring additional USB ports. Its robust design and flexible configuration options make it a preferred choice for expanding USB capabilities in consumer, commercial, and industrial products.

Package and Quality

Packaged in a 32-pin LQFP (VQFN) footprint, the TUSB2036VFR offers a compact solution for PCB design. Additionally, Texas Instruments ensures high standards of quality and reliability for their products, making the TUSB2036VFR a reliable component for any USB expansion project.
