Products specifications

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 34 Weeks
Features USB, UART Switch IC Channel 12-DSBGA
Manufacturer Texas Instruments
Package Reel - TR
Operating Temperature Range -40°C ~ 85°C
Mounting Surface Mount
Package 12-XFBGA, DSBGA
Case / Package 12-DSBGA
Family Name TS5USBC400
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number TS5USBC400IYFPR-ND, 296-52162-2, 296-52162-1, 296-52162-6
Quantity per package 3000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 901224-TS5USBC400IYFPR
Ultra Librarian 3D Model Ultra Librarian TS5USBC400IYFPR CAD Model

Description

The TS5USBC400IYFPR from Texas Instruments is a high-performance, bidirectional switch designed for USB Type-C™ applications. This advanced switch allows for the multiplexing and demultiplexing of differential signals such as USB SuperSpeed signals or DisplayPort signals, providing versatile connectivity options for a wide range of devices.

Key Features

  • USB Type-C™ Compatibility: The device is fully compliant with the USB Type-C™ standard, ensuring seamless integration with the latest USB technology.
  • High-Speed Data Transfer: It supports USB 3.1 Gen 1 (5 Gbps) data rates, enabling rapid data transfer and efficient operation for connected devices.
  • Flexible Signal Routing: The 2:1 configuration allows for the flexible routing of high-speed differential signals, making it ideal for multiplexing USB and DisplayPort interfaces.
  • Low On-Resistance: The switch features low on-resistance (RON) characteristics, minimizing signal attenuation and power loss for improved signal integrity.
  • ESD Protection: Integrated Electrostatic Discharge (ESD) protection circuits safeguard the device against static damage, enhancing system reliability.
  • Power Efficiency: The TS5USBC400IYFPR is designed for low-power operation, contributing to the energy efficiency of end products.

Applications

  • Smartphones and Tablets
  • Laptops and Ultrabooks
  • Docking Stations
  • Monitors and Displays
  • USB Hubs and Peripherals

With its robust design and advanced features, the TS5USBC400IYFPR is an ideal solution for manufacturers looking to enhance the connectivity and performance of their USB Type-C™ equipped devices. Texas Instruments' commitment to quality and innovation ensures that this switch provides reliable, high-speed data transfer capabilities to meet the demands of modern consumer electronics.
