Products specifications

Categories RF/IF and RFID
Estimated Pruduction Lead Time 5 Weeks
Features RF Amplifier IC Cellular, CATV, DBS 40MHz ~ 6GHz 8-WSON (2x2)
Manufacturer Texas Instruments
Package Reel - TR
Mounting Surface Mount
Package 8-WFDFN Exposed Pad
Case / Package 8-WSON (2x2)
Family Name TRF37A75
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.33.0001
Other Part Number TRF37A75IDSGR-ND, -296-41010-1-ND, 296-41010-6, 296-41010-1, 296-41010-2
Quantity per package 3000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 937535-TRF37A75IDSGR
Ultra Librarian 3D Model Ultra Librarian TRF37A75IDSGR CAD Model

Description

The TRF37A75IDSGR is a high-performance, wideband fixed gain amplifier designed and manufactured by Texas Instruments. This device is part of TI's extensive RF product line and is ideal for a variety of applications, including wireless infrastructure, RF/IF amplification, and general-purpose RF applications.

With a frequency range from 50 MHz to 6000 MHz, the TRF37A75IDSGR can be utilized in a broad spectrum of RF systems. It provides a fixed gain of 20 dB, which is beneficial in maintaining a consistent signal amplification across various signal strengths. This characteristic is particularly useful in applications where a stable gain is crucial for maintaining signal integrity.

The TRF37A75IDSGR is designed for excellent linearity and low noise figure, which ensures minimal distortion and high-quality signal amplification. This makes it suitable for demanding RF environments where signal purity is paramount. Texas Instruments has engineered this device with an OIP3 (Output Third-Order Intercept Point) of 39 dBm, which is indicative of its ability to handle high power levels without significant nonlinear distortion.

This amplifier is housed in a compact 4 mm x 4 mm QFN package, making it an ideal choice for space-constrained applications. Its small footprint allows for ease of integration into existing designs, providing a powerful yet efficient solution for amplifying RF signals. Additionally, the TRF37A75IDSGR operates over a wide temperature range, ensuring reliable performance under varying environmental conditions.

The device also features single-ended input and output, which simplifies the design and reduces the complexity of the RF signal chain. The TRF37A75IDSGR requires a single 5V supply voltage, making it compatible with many standard system power rails. Moreover, it comes with power-down capability, which is essential for power-sensitive applications, allowing users to reduce power consumption when the amplifier is not in use.

In summary, the TRF37A75IDSGR from Texas Instruments is a versatile and robust fixed gain amplifier that delivers consistent performance for a wide range of RF applications. Its combination of wideband capability, high linearity, and compact packaging makes it a top choice for engineers and designers looking to enhance their RF systems.
