TPS65130RGERG4 Real Image TPS65130RGERG4 real image13656 TPS65130RGERG4 real image13657
Same model may have multiple batches, images only for reference.
TPS65130RGERG4 Real Image TPS65130RGERG4 real image13656 TPS65130RGERG4 real image13657
TPS65130RGERG4 Real Image TPS65130RGERG4 real image13656 TPS65130RGERG4 real image13657
Same model may have multiple batches, images only for reference.

TPS65130RGERG4

Part No TPS65130RGERG4
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description POSITIVE AND NEGATIVE OUTPUT DC-DC CONVERTER
Datasheet
TPS65130RGERG4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Function Step-Up, Step-Up/Step-Down
Output Configuration Positive and Negative (Dual Rail)
Topology Boost, Buck-Boost
Output Type Adjustable
Number of Outputs 2
Input Voltage MIN 2.7V
Voltage Input MAX 5.5V
Output Voltage 3.2V, -2V
Output Voltage MAX 15V, -15V
Output Current 700mA (Switch)
Frequency - Switching 1.38MHz
Synchronous Rectifier No
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting SMD
Package 24-VFQFN Exposed Pad
Manufacturer Package 24-VQFN (4x4)
Win Source Part Number 1273005-TPS65130RGERG4
Manufacturer Homepage www.ti.com
Family Name TPS65130
Introduction Date September 01, 2004
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS65130RGERG4 CAD Model

Description

The TPS65130RGERG4 is an integrated circuit designed by Texas Instruments.

  • Supply and Demand Status: Balanced
  • Converter Type: Step-up/step-down
  • Output Type: Adjustable
  • Topology: Boost/Buck-Boost
  • Frequency Switching: 1.38MHz
  • Number of Outputs: Up to 2
  • Rectifier: Synchronous
  • Maximum Output Voltage: 15V, -15V
  • Output Current: 700mA
