Introducing the TPS3702CX33DDCR from Texas Instruments

The TPS3702CX33DDCR is a state-of-the-art voltage detector and supervisor IC designed by Texas Instruments, renowned for its precision and reliability. This compact, high-accuracy device is engineered to monitor voltage levels and provide system protection in a wide array of applications, from consumer electronics to industrial systems.

Key Features

• High Accuracy: The TPS3702CX33DDCR boasts an impressive threshold accuracy of ±0.5%, ensuring precise voltage monitoring and system reliability.
• Low Current Consumption: With a quiescent current of just 6.5 µA, this device is an excellent choice for power-sensitive applications, helping to extend battery life and reduce energy costs.
• Wide Voltage Range: The device is capable of monitoring voltage levels from 0.4 V to 5.5 V, making it versatile for various circuits and systems.
• Adjustable Delay Time: It features an adjustable delay time that can be set using an external capacitor, which allows for customized timing to meet specific system requirements.
• Dual-Sense Inputs: The TPS3702CX33DDCR includes two independent sense inputs that provide under-voltage and over-voltage detection, enhancing the protection of critical system components.

Applications

The versatility of the TPS3702CX33DDCR extends to multiple applications, including but not limited to:

• Portable and battery-powered equipment
• Microprocessor, microcontroller, or FPGA power supply monitoring
• Industrial equipment and PLCs (Programmable Logic Controllers)
• Automotive systems that require precise voltage supervision

Package and Quality

The TPS3702CX33DDCR comes in a compact, surface-mount SOT-23 package, which is suitable for space-constrained applications. Quality and reliability are assured, as Texas Instruments is committed to the highest standards of product excellence.

With its combination of features, the TPS3702CX33DDCR is an ideal solution for designers looking to incorporate a robust voltage supervision system that offers both flexibility and precision. Whether it's safeguarding sensitive electronics or ensuring the stability of power supplies, this device from Texas Instruments stands as a top-tier choice for voltage detection needs.
