Product Overview: TPS23753PW by Texas Instruments

The TPS23753PW is a versatile and highly integrated Power over Ethernet (PoE) controller developed by Texas Instruments. This advanced component is specifically designed to facilitate the implementation of Power Sourcing Equipment (PSE) in accordance with the IEEE 802.3af standard. The TPS23753PW combines a PoE interface with a DC-DC controller, enabling it to power up Ethernet devices directly through the network cable, thus eliminating the need for additional power supplies.

Key Features:

• Integrated PoE Interface: The TPS23753PW integrates the necessary protocols and signaling to communicate with Powered Devices (PDs) ensuring safe and reliable power delivery over Ethernet cabling.
• DC-DC Controller: The device includes a flexible DC-DC controller compatible with a variety of topologies such as flyback, forward, or buck-boost converters, providing design versatility.
• Advanced Protection: It incorporates numerous protection features, including over-current, over-voltage, under-voltage lockout, and thermal shutdown to ensure the safety and reliability of the power delivery system.
• Enhanced Thermal Performance: The TPS23753PW is available in a 20-pin TSSOP (PW) package, which offers excellent thermal performance, ensuring stable operation in diverse environments.
• IEEE 802.3af Compliant: This device fully complies with the IEEE 802.3af standard for PoE, allowing for a maximum power delivery of 15.4W per port, suitable for a wide range of applications.

Applications:

The TPS23753PW is ideal for a multitude of applications that require PoE capabilities. It is commonly used in:

• Network Cameras and Security Systems
• Wireless Access Points
• VoIP Phones
• Point of Sale (POS) Terminals
• Industrial Controls

With its robust feature set and compliance with the PoE standard, the TPS23753PW from Texas Instruments is a crucial component for designers and engineers looking to create efficient and reliable PSE solutions. Its integration of a PoE interface and a DC-DC controller into a single package makes it a compact and cost-effective choice for powering Ethernet devices.
