Product Overview: Texas Instruments TPS2216DAP

The TPS2216DAP from Texas Instruments is a highly versatile and efficient power distribution switch designed for applications requiring multiple power management solutions. This integrated circuit is part of TI's power interface portfolio, which is known for its reliability and performance in managing power distribution.

Key Features

• Dual-Slot Power Interface Switch: The TPS2216DAP is capable of independently controlling two slots, making it ideal for systems with multiple peripherals or cards.
• Programmable Current Limit: Users can set the current limit to match the requirements of their specific application, ensuring protection against overcurrent conditions.
• High Accuracy: The device boasts a current-limit accuracy of ±10%, providing precise control over the power supply to connected devices.
• Thermal Protection: With built-in thermal protection, the TPS2216DAP automatically shuts down if it detects an over-temperature condition, safeguarding the system from potential damage.
• Under-Voltage Lockout (UVLO): The UVLO feature ensures that the switch remains off if the input voltage drops below a certain threshold, preventing malfunction.

Applications

The TPS2216DAP is suitable for a wide range of applications, including but not limited to:

• Hot-plug power control in servers and workstations
• Power distribution for peripheral ports in desktops and laptops
• PCMCIA/CardBus slots
• Powered USB hubs and devices

Technical Specifications

• Package: 24-Pin HTSSOP (DAP)
• Input Voltage Range: 2.7V to 5.5V
• Operating Temperature Range: -40°C to 85°C

With its robust set of features and protections, the TPS2216DAP from Texas Instruments is a comprehensive solution for managing power distribution in a variety of electronic systems. Its precision and reliability make it a trusted choice for designers looking to integrate power management into their projects.
