The TPD2E009DBZR is a state-of-the-art transient voltage suppressor (TVS) designed by Texas Instruments (TI) to protect sensitive electronics from electrostatic discharge (ESD) and other voltage-induced transient events. This compact, low-capacitance device is a must-have for modern electronics where space is at a premium and protection is a necessity.

Key Features

• ESD Protection: The TPD2E009DBZR offers robust ESD protection for high-speed data lines, ensuring compliance with the IEC 61000-4-2 (ESD) standard, with ±8 kV (Contact) and ±15 kV (Air-gap) discharge protection.
• Low Capacitance: With a typical capacitance of only 0.65 pF, this device provides effective transient voltage suppression while maintaining signal integrity, making it ideal for high-speed interfaces such as USB 2.0, HDMI, and more.
• Small Package Size: Housed in a tiny 2-pin DBZ package, the TPD2E009DBZR occupies minimal board space, allowing for more compact circuit designs.
• Low Leakage Current: It features a low leakage current of less than 1 µA, contributing to the overall power efficiency of the system it protects.
• Wide Operating Range: The device operates over a broad temperature range from -40°C to 85°C, ensuring reliable protection across various environmental conditions.

Applications

The versatility of the TPD2E009DBZR makes it suitable for a wide array of applications. It is particularly well-suited for:

• Mobile Handsets
• Portable Electronics
• USB Interfaces
• HDMI Ports
• Notebooks, Desktops, and Servers
• Set-Top Boxes

Reliability and Quality

TI's commitment to quality ensures that the TPD2E009DBZR meets the highest standards of reliability and performance. Each device is rigorously tested to ensure it meets TI's stringent criteria for ESD protection, so you can design with confidence knowing your products are safeguarded against transient events.
