The TMUX1308DYYR is a cutting-edge, high-performance analog multiplexer from Texas Instruments. This precision device is designed to handle eight channels, providing a versatile solution for routing analog signals in a variety of electronic applications. The TMUX1308DYYR is ideal for use in test equipment, data acquisition systems, and battery-powered instruments, where efficient signal management is crucial.

Key Features

• Low On-Resistance: The TMUX1308DYYR boasts an exceptionally low on-resistance (Ron), typically around 5 ohms, which minimizes signal distortion and ensures high signal integrity.
• Wide Operating Range: This device operates over a wide supply range of ±5.5V to ±16.5V or a single supply of 10V to 16.5V, accommodating various application needs.
• Low Leakage Current: The leakage current is remarkably low, which is critical for maintaining accuracy in precision measurement systems.
• Extended Temperature Range: With an operational temperature range of -40°C to 125°C, the TMUX1308DYYR is suitable for use in harsh environments.
• Break-Before-Make Switching: This feature prevents signal overlap during channel-to-channel transitions, thereby reducing the chance of transient errors in signal routing.

Applications

The versatility of the TMUX1308DYYR makes it an excellent choice for a wide array of applications, including:

• Data acquisition systems
• Signal routing
• Audio and video switching
• Automated test equipment
• Instrumentation
• Medical equipment

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the TMUX1308DYYR is no exception. It is manufactured using the latest techniques to ensure high reliability and performance under varying conditions. Furthermore, the device comes in a compact VSSOP-16 package, making it easy to integrate into space-constrained designs.

Ordering Information

The TMUX1308DYYR is available for order in different quantities to meet the needs of both small-scale projects and large-volume production. For detailed pricing and availability, please visit the Texas Instruments website or contact an authorized distributor.
