TMUX1113RSVR Precision Analog Multiplexer

The TMUX1113RSVR from Texas Instruments is a state-of-the-art precision analog multiplexer designed for a variety of applications, including test equipment, data acquisition systems, and battery-powered instruments. This advanced component is part of Texas Instruments' commitment to providing high-performance solutions for complex electronics systems.

Featuring a single 8:1 or dual 4:1 multiplexing configuration, the TMUX1113RSVR offers designers flexibility in integrating the device into their circuits. The multiplexer operates with a single supply ranging from 1.08 V to 5.5 V, which makes it suitable for low-voltage and portable applications. Additionally, it is fully specified for operation from -40°C to 125°C, ensuring reliable performance across a wide range of environmental conditions.

One of the key attributes of the TMUX1113RSVR is its low on-resistance (RON) of typically 100 ohms, which minimizes signal distortion and allows for the passage of high-quality analog signals. This low RON is matched with a flatness of just 6 ohms, ensuring consistent performance across the entire signal range. The device also boasts low charge injection, which reduces switching transients and improves overall system accuracy.

The TMUX1113RSVR incorporates fail-safe logic, which ensures that the signal path remains in a high-impedance state if the power supply is lost. This feature is critical for applications that require fail-safe operations to prevent damage to the system or to ensure data integrity during power loss scenarios.

To facilitate easy integration into digital systems, the TMUX1113RSVR supports both 1.8 V and 5 V logic inputs, making it compatible with a broad range of microcontrollers and digital interfaces. The device is offered in a compact, space-saving 10-pin VSSOP package, which is ideal for applications where board space is at a premium.

Overall, the TMUX1113RSVR is a highly versatile and reliable component that provides designers with the performance and flexibility needed to create sophisticated analog signal routing solutions. Its precision specifications and robust feature set make it an excellent choice for mission-critical applications in industrial, communications, and healthcare electronics.
