TLV2375ID Operational Amplifier by Texas Instruments

The TLV2375ID is a high-performance, rail-to-rail input and output operational amplifier (op-amp) from Texas Instruments, designed to operate with single or dual supplies. This versatile op-amp is part of the TLV237x family, which is well-suited for a wide range of applications due to its low input bias current, low noise, and low power consumption.

Key Features

• Supply Voltage Range: The TLV2375ID operates across a broad supply voltage range of 2.7V to 16V, making it adaptable for various applications from battery-powered devices to industrial controls.
• Rail-to-Rail Input/Output: The device offers rail-to-rail input and output swing, which extends the dynamic range and enables it to drive loads close to the power supply rails, maximizing efficiency.
• Low Noise: With a low noise density of 25nV/√Hz at 1kHz, the op-amp is an excellent choice for audio and other sensitive applications where noise performance is critical.
• Low Input Bias Current: The input bias current is as low as 1pA, which is ideal for applications requiring high input impedance.
• High Output Drive Capability: The TLV2375ID can drive up to 50mA of load current, offering robust performance for a variety of loads.
• Extended Temperature Range: It is designed to operate over an extended industrial temperature range of -40°C to 125°C, ensuring reliability in harsh environments.

Applications

The TLV2375ID is a versatile component that can be used in a multitude of applications, including:

• Portable and battery-operated devices
• Analog signal conditioning
• Active filters and amplifiers
• Data acquisition systems
• Audio processing
• Sensors and controls

Package and Quality

The TLV2375ID is offered in the industry-standard SOIC-14 package, which ensures compatibility with a wide range of PCB designs. Texas Instruments is known for its commitment to quality, and this op-amp is no exception, meeting high standards of performance and reliability.
