The TLIN24413DMTTQ1 from Texas Instruments is a robust, automotive-grade, quad-channel Local Interconnect Network (LIN) transceiver designed to interface microcontrollers with LIN bus systems in automotive and industrial applications. This advanced transceiver conforms to LIN 2.x, SAE J2602, and ISO 17987-4 standards, ensuring high interoperability and reliability in harsh environments.

Key Features

• Automotive Qualified: The TLIN24413DMTTQ1 is AEC-Q100 qualified, making it suitable for automotive applications where reliability and performance under extreme conditions are paramount.
• Quad-Channel Interface: It features four independent LIN transceiver channels, allowing for multiple LIN networks to be driven by a single device, which can significantly reduce system complexity and cost.
• Wide Operating Voltage: With an operating voltage range from 5.5 V to 27 V, this transceiver offers great flexibility and is resilient to voltage fluctuations typically found in automotive power systems.
• Thermal Shutdown: Enhanced thermal shutdown protection ensures the device operates within safe temperature limits, providing additional safety and reliability.
• Low-Power Mode: The device supports a low-power sleep mode with a typical current draw of 15 µA, which is crucial for battery-powered applications where power conservation is critical.
• Robust ESD Protection: It offers excellent Electrostatic Discharge (ESD) protection, ensuring the device's longevity in environments prone to electrical disturbances.

Applications

The TLIN24413DMTTQ1 is ideal for a range of applications within the automotive sector, including but not limited to:

• Body Control Modules
• Steering Wheel Functions
• Rain and Light Sensors
• Door and Window Controls
• Climate Controls

Package and Availability

This transceiver is offered in a 16-pin HTSSOP package, which is designed for space-constrained applications. It is available for purchase through Texas Instruments and authorized distributors, ensuring easy access to this high-quality component for your automotive solutions.
