Product Overview: TL431BIDBZRG4

The TL431BIDBZRG4 is a precision programmable reference from Texas Instruments, designed to offer a reliable solution for voltage regulation in a multitude of applications. This versatile three-terminal adjustable shunt regulator is commonly used in power supplies, battery chargers, and voltage monitoring systems, providing a cost-effective yet highly accurate method of setting a voltage level or maintaining a constant voltage in a circuit.

With its adjustable output voltage that can be set from 2.495 V to 36 V with two external resistors, the TL431BIDBZRG4 offers excellent design flexibility. The device features a typical temperature coefficient of only 50 ppm/°C, ensuring stable operation over a wide temperature range, which is particularly important for applications requiring consistent performance regardless of external conditions.

The TL431BIDBZRG4 comes in a small surface-mount package, specifically the SOT-23-3, which is ideal for space-constrained applications. Its small footprint allows it to be used in compact designs without sacrificing power or precision. The device's low output noise and excellent accuracy, with a tolerance of 0.5% at 25°C, make it a preferred choice for high-performance systems.

Safety and reliability are key concerns in electronic design, and the TL431BIDBZRG4 addresses these with features such as overcurrent protection and thermal stability. It can operate over a full industrial temperature range of -40°C to +85°C, which is testament to its robustness and suitability for challenging environments.

In summary, the Texas Instruments TL431BIDBZRG4 is a versatile and precise adjustable shunt regulator that offers designers the flexibility to create stable voltage references in a wide range of applications. Its high accuracy, low temperature coefficient, and small package size make it an excellent choice for sophisticated electronic systems where space and reliability are at a premium.
