Product Overview: Texas Instruments TL431BIDBVT

The TL431BIDBVT from Texas Instruments is a highly versatile three-terminal adjustable shunt regulator with specified thermal stability over applicable automotive, commercial, and military temperature ranges. This integrated circuit is available in a compact SOT-23 package, designed for easy implementation in a wide array of applications requiring a reliable voltage reference.

This device offers excellent temperature stability and output current handling capability up to 100 mA. The output voltage can be set to any value between Vref (approximately 2.495 V) and 36 V with two external resistors. This flexibility makes the TL431BIDBVT an ideal choice for precision voltage regulation in critical applications.

Key Features

• Adjustable Output Voltage: The output voltage can be set from 2.495 V to 36 V, providing a versatile solution for various applications.
• Low Output Noise: It provides a low-noise voltage reference, which is crucial for sensitive electronics and precision instrumentation.
• High Stability: The device offers exceptional stability over its full operating temperature range, ensuring reliable performance under varying conditions.
• Low Dynamic Output Impedance: Its low output impedance and fast turn-on response make it suitable for applications requiring a high-performance regulator.

Applications

• Power supplies
• Battery chargers
• Switching power supplies
• Adjustable voltage references
• Current limiters

The TL431BIDBVT is an essential component for designers looking for a stable and adjustable voltage reference. Its precision and reliability are backed by Texas Instruments' commitment to high-quality semiconductor solutions. Whether it's used in power supply units or as a part of a more complex circuit, the TL431BIDBVT delivers consistent performance, enhancing the overall stability and efficiency of electronic systems.

With its robust design and comprehensive feature set, the TL431BIDBVT is a valuable addition to any electronic project requiring precise voltage control. Its small form factor also makes it ideal for space-constrained applications, providing the perfect balance between functionality and size.
