SN74LVTH32244ZKER: 32-Bit Buffer/Driver with 3-State Outputs

The SN74LVTH32244ZKER is a high-performance integrated circuit from Texas Instruments designed for use in a wide range of digital applications. This 32-bit buffer/driver component is part of the LVT family, which offers low-voltage, high-speed operation. Equipped with 3-state outputs, the SN74LVTH32244ZKER is ideal for driving bus lines or buffer memory address registers.

Key Features

• Technology: The device is built on advanced BiCMOS technology, which combines the strengths of CMOS and bipolar transistors to deliver high speed and low power consumption.
• Operating Voltage: It operates at a nominal voltage of 3.3V, making it compatible with modern low-voltage systems while also providing 5V tolerant I/Os.
• Drive Capability: The SN74LVTH32244ZKER has high drive capability, with outputs capable of sourcing and sinking significant current, which is ideal for driving heavy loads.
• 3-State Outputs: The 3-state outputs allow for connection to a bus without interfering with other devices that may be communicating. This feature is critical for multiplexed bus systems.
• Package: It is available in an 80-pin R-LQFP (ZKE) package, which is suitable for surface-mount technology and provides space-saving advantages on printed circuit boards.

Applications

The SN74LVTH32244ZKER is versatile and can be used in various applications, including:

• Bus interface buffers
• Memory address drivers
• Data communication systems
• Servers and networking equipment
• Signal distribution and transmission

Performance and Quality

With Texas Instruments' reputation for quality, the SN74LVTH32244ZKER is manufactured to high standards, ensuring reliable performance in demanding environments. The device also supports a wide temperature range, making it suitable for industrial applications.

Overall, the SN74LVTH32244ZKER from Texas Instruments is a robust, high-speed buffer/driver that provides designers with a reliable solution for data transmission and signal buffering needs in complex digital systems.
