Product Description: SN74LVC373APWR from Texas Instruments

The SN74LVC373APWR is a high-quality, high-performance Octal Transparent D-Type Latch with 3-State Outputs from the globally recognized semiconductor manufacturer, Texas Instruments. This device is designed to perform at the highest level, providing robust and reliable functionality to a variety of applications.

The SN74LVC373APWR is designed with 8-bit latches that are controlled by latch-enable (LE) and output-enable (OE) inputs. When LE is high, the outputs follow the data (D) inputs. When LE is taken low, the data that met the setup times is latched. Data appears on the bus when the OE input is low and is stored during the high-to-low OE transition.

This device is also equipped with 3-state outputs that are designed to drive bus lines directly. The 3-state control gate is a 2-input AND gate with active-low inputs so that if one or both of the OE or LE inputs is high, the outputs are in the high-impedance state. However, the latch-enable (LE) and output-enable (OE) inputs are supplied by a latch so that the falling edge of LE can be used to store data.

The SN74LVC373APWR is fabricated using an advanced CMOS process to achieve high-speed operation. This device is designed to operate from 1.65 V to 3.6 V, with inputs that are tolerant to 5.5 V, allowing the interface of 5-V systems to 3.3-V systems.

With a wide operating temperature range of -40°C to 85°C, it is suitable for a variety of challenging environments. It comes in a TSSOP (PW) 20 pin package, ensuring compactness and ease of integration into various systems.

In conclusion, the SN74LVC373APWR from Texas Instruments is a reliable, versatile, and high-performing solution for your latching needs.
