The SN74LVC1G132DBVR from Texas Instruments is a high-performance, single 2-input NAND gate with Schmitt-trigger inputs that is designed for 1.65-V to 5.5-V V_CC operation. This small and efficient logic gate is an ideal choice for a wide range of applications, from consumer electronics to industrial control systems.

Key Features:

• Logic Type: 2-Input NAND Gate
• Operating Voltage: 1.65 V to 5.5 V
• Output Drive Capability: ±8-mA at 5 V
• Schmitt-Trigger Inputs: Provide noise immunity and allow for slow input transition
• Low Power Consumption: ICC of 10 µA maximum
• High Frequency: f_max of 24 MHz at 3.3 V
• Package: SOT-23-5

Product Description:

The SN74LVC1G132DBVR is a single 2-input NAND gate with Schmitt-trigger inputs that incorporate Texas Instruments' LVC (Low-Voltage CMOS) technology. This allows the device to operate at a voltage range of 1.65 V to 5.5 V, making it suitable for interfacing with both 3.3 V and 5 V systems. The Schmitt-trigger inputs increase the hysteresis of the input signal, providing excellent noise immunity and enabling the gate to handle slower input signal rise and fall times.

With the ability to drive ±8 mA at 5 V, it can easily drive larger loads or interface with other logic levels. The low power consumption with a maximum ICC of 10 µA contributes to energy-efficient designs, which is critical in battery-operated and power-sensitive applications.

Its high-frequency operation capability, with a maximum frequency of 24 MHz at 3.3 V, makes it suitable for high-speed signal processing applications. The compact SOT-23-5 package allows for efficient use of board space, which is especially beneficial in space-constrained applications.

The SN74LVC1G132DBVR is characterized for operation from -40°C to 85°C, ensuring reliable performance across a wide range of environmental conditions. Whether you're designing consumer electronics, communication devices, or complex computing systems, the SN74LVC1G132DBVR provides a reliable and efficient solution for your NAND gate logic requirements.
