The SN74HC42D is a high-performance integrated circuit from Texas Instruments, designed to address the need for efficient decoding and demultiplexing in digital systems. This IC is part of the 74HC series, which is renowned for its high-speed CMOS logic family that strikes a balance between speed and power consumption.

Key Features

• Wide Operating Voltage Range: The SN74HC42D operates at a voltage range of 2 V to 6 V, making it versatile for various applications and compatible with many other logic families.
• High Current Drive: This device is capable of driving up to 5.2 mA at the output, allowing it to drive larger loads than standard CMOS outputs.
• Low Power Consumption: With a typical power consumption of only 20 µA, the SN74HC42D is ideal for power-sensitive applications.
• 4-Line to 10-Line Decoding: The decoder accepts four binary weighted inputs (A0 to A3) and provides ten mutually exclusive outputs (Y0 to Y9), which are ideal for creating 10 decimal digits from binary input.

Applications

The SN74HC42D is suitable for a wide range of applications, including:

• Logic level conversion for interfacing different voltage levels within a system
• Decoding binary information to drive decimal displays
• Demultiplexing signals for routing data to multiple destinations
• Use in control systems, computing, and telecommunication systems

Quality and Reliability

Texas Instruments is committed to high standards of quality and reliability, and the SN74HC42D is no exception. This device is rigorously tested and ensured to meet the stringent requirements for commercial and industrial temperature ranges.

Package Information

The SN74HC42D comes in a SOIC-16 package, which is a small outline integrated circuit with 16 pins. This package is widely used and preferred for its small size and ease of surface mounting on printed circuit boards.
