The SN74HC125PWR is a high-performance, advanced chip device manufactured by the globally recognized company, Texas Instruments.

• Function: Quadruple bus buffer gate with 3-state outputs
• Series: SN74HC
• Gates: Four independent gates, each performing the Boolean function Y = A in positive logic
• Outputs: 3-state, controlled by output-enable (OE) inputs
• OE Low: Output is in the 2-state
• OE High: Output is in the high-impedance state
• Voltage Range: 2V to 6V
• Current: Up to ±6mA
• Package: TSSOP (Thin Shrink Small Outline Package) of 14 pins
• Operating Temperature Range: -40°C to 85°C
• Standard: Meets or exceeds the requirements of ANSI Standard TIA/EIA-422-B and ITU Recommendation V.11
