SN74ACT14PW Real Image SN74ACT14PW real image5853
Same model may have multiple batches, images only for reference.
SN74ACT14PW Real Image SN74ACT14PW real image5853
SN74ACT14PW Real Image SN74ACT14PW real image5853
Same model may have multiple batches, images only for reference.

SN74ACT14PW

Part No SN74ACT14PW
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC HEX SCHMITT-TRIG INV 14-TSSOP
Datasheet
SN74ACT14PW Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 6
Number of Inputs 6
Features Schmitt Trigger
Supply Voltage - Operating 4.5 V to 5.5 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 24mA, 24mA
Logic Level - Low 0.5 V to 0.6 V
Logic Level - High 1.9 V to 2.1 V
Max Propagation Delay @ V, Max CL 11.5ns @ 5V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-TSSOP
Dimension 14-TSSOP (0.173", 4.40mm Width)
Win Source Part Number 082198-SN74ACT14PW
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SN74ACT14PW CAD Model

Description

The SN74ACT14PW from Texas Instruments is a high-performance, advanced CMOS (Complementary Metal-Oxide-Semiconductor) device that has been meticulously designed to offer superior functionality and performance.

  • Device Type: Hex inverter
  • Inputs: Schmitt-trigger inputs
  • Operating Voltage Range: 4.5 V to 5.5 V
  • Noise Immunity: Typically 1 V
  • Operating Temperature: -40°C to 85°C
  • Power Consumption: Low power consumption
  • Package: 14-pin TSSOP (Thin Shrink Small Outline Package)
  • RoHS Compliant: Yes
