Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 50mV
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating -40°C to 105°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 084077-SN65176BD
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN65176BD CAD Model

Description

The SN65176BD from Texas Instruments is an advanced differential bus transceiver that is specifically designed to meet the rigorous demands of industrial applications.

  • Type: Half-duplex transceiver
  • Power Supply: Single 5V power supply
  • Feature: High immunity to noise and electrical interference
  • Data Transmission: Differential
  • Feature: High driver output capability
  • Feature: Thermal shutdown protection
  • Package: Compact 8-pin SOIC package
  • Feature: Wide common-mode voltage range
