SN54LS08J Real Image
Same model may have multiple batches, images only for reference.

SN54LS08J

Part No SN54LS08J
Manufacturer Texas Instruments
Catalog HOT - SALES and EOL Components (S)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Win Source Part Number 330419-SN54LS08J
Popularity Low
Supply and Demand Status Limited
Package Tube
Product Status Active
Logic Type AND Gate
Number of Circuits 4
Number of Inputs 2
Voltage - Supply 4.5 V ~ 5.5 V
Current - Quiescent (Max) 8.8 mA
Current - Output High, Low 400µA, 4mA
Input Logic Level - Low 0.7V
Input Logic Level - High 2V
Max Propagation Delay @ V, Max CL 20ns @ 5V, 15pF
Operating Temperature -55°C ~ 125°C
Grade -
Mounting Type Through Hole
Supplier Device Package 14-CDIP
Package / Case 14-CDIP (0.300\
Ultra Librarian 3D Model Ultra Librarian SN54LS08J CAD Model

Description

The SN54LS08J is an advanced integrated circuit (IC) from the renowned manufacturer, Texas Instruments.

  • Type: Quad 2-input positive AND gate device.
  • Gates: Designed with four independent gates, each capable of performing the logical AND function.
  • Technology: Built using low power Schottky technology, which is designed to provide high speed and low power consumption.
  • Package: Comes in a 14-pin ceramic flat package.
  • Temperature Range: Characterized for operation over the full military temperature range of -55°C to 125°C.
  • Interface Capability: Direct interface capability with the TTL family.
