Products specifications

Manufacturer Texas Instruments
Packaging Tube
Applications Voltage Feedback
Output Type Rail-to-Rail
Number of Circuits 1
-3db Bandwidth 170MHz
Slew Rate 900V/μs
Current - Supply 14mA
Current - Output / Channel 100mA
Voltage - Supply, Single/Dual (±) 2.7V ~ 16V, ±1.35V ~ 8V
Mounting Style SMD
Manufacturer Package 8-TSSOP, 8-MSOP Exposed Pad
Supplier Device Package 8-MSOP-PowerPad
Part Number Series SN10501
Manufacturer Pack Quantity 80
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 810884-SN10501DGN
Ultra Librarian 3D Model Ultra Librarian SN10501DGN CAD Model

Description

Texas Instruments presents the SN10501DGN, a high-performance, dual non-inverting buffer/driver designed to deliver precision and power in a wide range of applications. This device is part of the SNx5xx01 series, which is known for its reliability and versatility in the electronics industry.

Key Features

  • High-Drive Outputs: The SN10501DGN can deliver high-current drive capability, which is ideal for driving heavy loads, such as transformers, LEDs, and other high-demand components.
  • Wide Operating Voltage Range: With an operating voltage range from 2V to 5.5V, this buffer/driver is suitable for a variety of power supply conditions, making it extremely versatile for different design requirements.
  • Fast Switching Times: The device boasts fast switching times, ensuring quick response and efficient operation in high-speed signal processing applications.
  • Low Power Consumption: Despite its high-drive capabilities, the SN10501DGN is designed to consume minimal power, which helps in reducing the overall power consumption of the system.
  • Robust Thermal Performance: Encased in an 8-pin MSOP (DGN) package, the SN10501DGN offers excellent thermal performance, ensuring stability even under high load conditions.
  • Wide Temperature Range: This device is operational over a wide temperature range, making it suitable for industrial and automotive applications that require consistent performance in varying environmental conditions.

Applications

The SN10501DGN is designed to be used in a range of applications including, but not limited to, line drivers, level translators, and as a buffer for driving high-capacitance loads. Its robust design makes it particularly well-suited for harsh industrial environments, as well as precision-focused applications such as test and measurement equipment, data acquisition systems, and high-speed communications interfaces.

Quality and Reliability

As with all Texas Instruments products, the SN10501DGN is manufactured to the highest quality standards, ensuring both reliability and performance. Whether you're designing consumer electronics or complex industrial systems, this buffer/driver is engineered to meet your needs and exceed expectations.
