Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Reference Type Series
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 3V
Output Current 10mA
Tolerance ±0.1%
Temperature Coefficient 8ppm/°C
Noise - 0.1Hz to 10Hz 3μVp-p
Voltage - Input 3.2 V to 18 V
Operating Supply Current 1.2mA
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 027326-REF5030AIDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian REF5030AIDR CAD Model

Description

The REF5030AIDR from Texas Instruments is a high-performance, low-drift voltage reference that offers precision and stability in a compact, surface-mount package.

  • Output Voltage: 3.0V
  • Initial Accuracy: 0.05%
  • Temperature Drift: 3ppm/°C
  • Supply Current: only 1.4mA
  • Output Current: up to 10mA
  • Output Noise: 3µVp-p/V
  • Operating Temperature Range: -40°C to +125°C
