PTV12020WAH Real Image
Same model may have multiple batches, images only for reference.

PTV12020WAH

Part No PTV12020WAH
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description REG SW 1.2-5.5V 16A VRT TH 12SIP
Datasheet
PTV12020WAH Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount
Family DC DC Converters
Manufacturer Texas Instruments
Series PTV12020
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 10.8V
Voltage - Input (Max) 13.2V
Voltage - Output 1 1.2 ~ 5.5 V
Current - Output (Max) 16A
Applications ITE (Commercial)
Features UVLO
Mounting Style Through Hole
Package 12-SIP Module
Size / Dimension 1.75" L x 0.37" W x 0.50" H (44.5mm x 9.4mm x 12.7mm)
Operating Temperature Range -40°C ~ 85°C
Efficiency 93%
Power (Watts) - Max 88W
Win Source Part Number 210353-PTV12020WAH
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PTV12020WAH CAD Model

Description

The PTV12020WAH is an innovative and high-performance power module from Texas Instruments, a leading global semiconductor company.

  • Manufacturer: Texas Instruments
  • Input Voltage: 12V
  • Output Current: Up to 20A
  • Input Voltage Range: 10.8V to 13.2V
  • Output Voltage Range: Broad output voltage range from 0.8V to 5.5V
  • Voltage Adjustment: Output voltage can be adjusted by using an external resistor
  • Protection Features: Over-temperature protection, output over-current protection, and input under-voltage lockout
  • Integration: High level of integration
  • Package: Compact, surface-mount
  • Pinout: Industry-standard
  • Efficiency: Superior efficiency
