PTN78020WAD

Part No PTN78020WAD
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description REG SW WIDE-VIN 6A ADJ T/H
Datasheet
PTN78020WAD Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount
Family DC DC Converters
Manufacturer Texas Instruments
Series PTN78020W
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 7V
Voltage - Input (Max) 36V
Voltage - Output 1 2.5 ~ 12.6 V
Current - Output (Max) 6A
Applications ITE (Commercial)
Mounting Style Through Hole
Package 7-DIP Module
Size / Dimension 1.50" L x 0.87" W x 0.35" H (38.1mm x 22.1mm x 8.9mm)
Operating Temperature Range -40°C ~ 85°C
Efficiency 94%
Power (Watts) - Max 75.6W
Win Source Part Number 210348-PTN78020WAD
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PTN78020WAD CAD Model

Description

The PTN78020WAD is an innovative, high-performance product from Texas Instruments, a global leader in technology and semiconductor manufacturing.

  • Type: Adjustable switching regulator module (DC-DC converter)
  • Input Voltage Range: Wide-input voltage range of 14.4V to 36V
  • Efficiency: High-efficiency power conversion, up to 96%
  • Output Voltage: Adjustable output voltage from -6V to -15V
  • Output Current: Maximum output current of 6A
  • Protection: On/off inhibit, under-voltage lockout, over-current protection, and over-temperature shutdown
  • Design: Compact, surface-mount
  • Compliance: RoHS compliant
