Same model may have multiple batches, images only for reference.
PTH04T240FAZ Texas Instruments – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

PTH04T240FAZ

Part No PTH04T240FAZ
Manufacturer Texas Instruments
Catalog DC DC Converters
Description DC DC CONVERTER 0.7-2V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 2.2V
Voltage - Input (Max) 5.5V
Voltage - Output 1 0.7 ~ 2V
Current - Output (Max) 10A
Applications ITE (Commercial)
Features Remote On/Off, OCP, OTP, UVLO
Temperature Range - Operating -40°C ~ 85°C
Efficiency 91%
Mounting Type Surface Mount
Case / Package 11-SMD Module
Size / Dimension 0.87" L x 0.62" W x 0.35" H (22.1mm x 15.7mm x 8.9mm)
Package Bulk;Tray
Supply and Demand Status Shortage
Win Source Part Number 1538730-PTH04T240FAZ
Ultra Librarian 3D Model Ultra Librarian PTH04T240FAZ CAD Model
