Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of I/O 16
Interrupt Output Yes
Features POR
Output Type Push-Pull
Current - Output Source/Sink 10mA, 25mA
Max Frequency 400kHz
Supply Voltage - Operating 2.3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 24-SOIC
Win Source Part Number 144775-PCA9535DWR
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PCA9535DWR CAD Model

Description

The PCA9535DWR is a high-quality, reliable semiconductor product from Texas Instruments, a renowned global manufacturer of semiconductors and various integrated circuits.

  • Function: 16-bit I2C and SMBus, low power I/O expander with interrupt output and configuration registers
  • Package: Surface-mount SOIC package with a wide body and 24 pins
  • I2C Interface: Supports standard (100 kHz), fast (400 kHz), and high-speed (3.4 MHz) modes
  • Standby Current: Low standby current
  • I/O Port Expander: 16-bit I/O port expander
  • Interrupt Output: Yes
  • Configuration Registers: Can be used to modify the functionality of the I/O ports
  • Supply Voltage Range: 2.3V to 5.5V
  • Operating Temperature: -40°C to +85°C
